Hydraulic motor HMB080 high performance hmb motor

HMB080 hydraulic motor, standard Displacement 1344cm3/r, optional non-standard Displacement 1250 cm3/r;1100 cm3/r. Rated Pressure 210bar, Rated Power 76KW.
The HMB080 hydraulic motor is a compact and powerful motor designed for use in industrial applications. It is manufactured by Bosch Rexroth, a leading provider of hydraulic and pneumatic components and systems.
The HMB080 is a gero-torque motor, which means it converts hydraulic fluid pressure into mechanical work through the principle of the gerotor. This type of motor is known for its compact size and high torque output, making it suitable for applications that require significant force.
  • HMB080

Availability:
Quantity:
twitter sharing button
wechat sharing button
line sharing button
pinterest sharing button
kakao sharing button
snapchat sharing button
telegram sharing button
whatsapp sharing button
facebook sharing button
linkedin sharing button
sharethis sharing button

Product Introduction

HMB080  is designed for use in industrial applications and is characterized by its compact size and high torque output.Here are some key features of the HMB080 hydraulic motor:

  • Compact Design: The HMB080 has a small footprint, making it ideal for use in space-constrained applications.

  • High Torque: This motor can generate high torque even at low speeds, making it suitable for applications that require significant force.Durable

  • Construction: The motor is constructed using high-quality materials that are designed to withstand the rigors of industrial use.

  • Easy Maintenance: The motor is designed with easy access to key components, making it easy to perform routine maintenance and repairs.

  • Versatile Application: The HMB080 can be used in a variety of industrial applications, including mobile equipment, construction machinery, and agricultural equipment.

When selecting a hydraulic motor for your application, it's important to consider factors such as the motor's maximum torque, speed range, and power requirements. The HMB080 hydraulic motor is a good option for many industrial applications due to its compact size and high torque output. However, it's always best to consult with a qualified hydraulic systems expert to ensure that the motor is suitable for your specific needs and operating conditions


Technical Parameters

Motor type
Metric

Geometric
displacement
mL/r

Average
actual
running
torque
(Nm/bar)

SPEED

PRESSURE

OUTPUT POWER

Rated.
rpm

Max.
rpm

Rated.
bar

Max.
bar

Rated.
KW

Max.
KW

B080

1344

19.23

180

225

210

275

76

90

B080/1250

1250

17.69

195

240

210

275

75

90

B080/1100

1100

15.40

215

275

210

275

72

86


FAQ

FAQs
  • 1、Is the installation dimension of your HMB080 hydraulic motor the same as the original motor from UK, and do any modifications need to be made during installation?
    Created with Sketch.
    形状 Created with Sketch.
    Our HMB080 hydraulic motor is as the same installation dimension as the original UK motor Which can be used without any modifications. When the it is the same model, it will be the all the same installment dimension. But the motorcase diameter is φ526mm, which is 29mm larger than the motorcase diameter of the UK Orignal HMB080 hydraulic motor.
  • Is the Accessories of your HMB080 hydraulic motor interchangeable and compatible with the original one from the UK?
    Created with Sketch.
    形状 Created with Sketch.
    Motorcase, Piston, and Con-rod of our HMB080 hydraulic motor are different the original one from the UK. The rest are the same as UK accessories.
  • How many sizes of main ports are available selection for your HMB080 hydraulic motor?
    Created with Sketch.
    形状 Created with Sketch.
    The main port :FM3/S03/SM3/SFM3/FM4.
  • What are the temperature requirements for the hydraulic motor?
    Created with Sketch.
    形状 Created with Sketch.
    Min. ambient temperature:-30°C
    Max. ambient temperature:+70°
    Min. working oil temperature:-20°C
    Max. working oil temperature:+54°C
