HMB125 hmb motor high performance for swing cylinder

HMB125 hmb motor high performance for swing cylinder

HMB125 hydraulic motor, standard Displacement 2050cm3/r, optional non-standard Displacement 1800 cm3/r. Rated Pressure 210bar, Rated Power 117KW.
In terms of its application, the HMB125 hydraulic motor can be used in a variety of industrial settings where hydraulic power is required, such as construction equipment, mining machinery, and other heavy-duty applications. It is typically used to convert hydraulic energy into mechanical energy, providing the necessary torque and speed to drive various types of machinery and equipment.It's worth noting that specific performance and characteristics may vary depending on the manufacturer and model, so it's important to consult the manufacturer's datasheet or catalog for detailed information and recommendations. Additionally, proper maintenance and regular inspections are crucial to ensure the long-term reliability and performance of the HMB125 hydraulic motor

Model:
HMB125

Quantity:
Availability:





Inquire Add to Basket

Product Introduction

HMB125 hydraulic motor, standard Displacement 2050cm³/r, optional non-standard Displacement 1800 cm³/r. Rated Pressure 210bar, Rated Power 117KW.

HMB125 hydraulic motor is a type of hydraulic motor commonly used in industrial applications. It has the following key features and specifications:

Nominal power: 125 kW, which indicates the maximum power output of the motor when operating under specified conditions.
Max. rated pressure: 210 bar, which is the maximum pressure the motor can withstand without experiencing excessive stress or damage.
Max. speed: 1500 r/min, which is the maximum rotational speed of the motor's output shaft.
Direction of rotation: clockwise (when viewed from the motor's output shaft end), which specifies the direction in which the motor's output shaft rotates.
Mounting dimensions: 280 mm x 200 mm, which indicates the dimensions required for mounting the motor to a supporting structure or machine.
Weight: 145 kg, which is the weight of the motor when fully assembled and ready for use.

Technical Parameters

Motor type Metric	Geometric displacement mL/r	Average actual running torque (Nm/bar)	SPEED		PRESSURE		OUTPUT POWER
Motor type Metric	Geometric displacement mL/r	Average actual running torque (Nm/bar)	Rated. rpm	Max. rpm	Rated. bar	Max. bar	Rated. KW	Max. KW
B125	2050	28.00	190	215	210	275	117	140
B125/1800	1800	24.04	215	255	210	275	114	136

Installation Dimensions

Installation Dimensions for HMB125.pdf

FAQ

FAQs

Is the installation dimension of your HMB125 hydraulic motor the same as the original motor from UK, and do any modifications need to be made during installation?

Yes. Our HMB125 hydraulic motor has the same installation dimension as the original motor from UK, and it can be used without any modifications. As long as the model is confirmed to be the same, all the installation dimensions of the motor will be exactly the same as this. You can help ensure that your HMB125 hydraulic motor operates efficiently and reliably for many years to come. Regular maintenance, proper operation, and attention to detail are key factors in maintaining the performance and longevity of your hydraulic motor.
2. Is the Accessories of your HMB125 hydraulic motor interchangeable and compatible with the original one from the UK?

A: Yes. The accessories of our HMB125 hydraulic motor are same as the original from UK.
Here are some common accessories that may be included with the HMB125 hydraulic motor:
Hydraulic hoses and fittings: These are essential for connecting the hydraulic motor to the hydraulic system, allowing the flow of hydraulic fluid to and from the motor.
Pressure gauges and sensors: These devices can be used to monitor the pressure and flow rate of the hydraulic fluid, ensuring that the motor is operating within its recommended parameters.
Mounting brackets and fasteners: These components are used to secure the hydraulic motor to the supporting structure or machine, ensuring that it remains in place during operation.
Oil level sight glass: This is a clear window that allows you to visually inspect the oil level in the hydraulic motor, helping you to monitor and maintain proper lubrication.
Drain plugs and breathers: These components help to prevent moisture and contaminants from entering the hydraulic motor, maintaining its performance and longevity.
If you have any specific questions or concerns about the accessories that come with your HMB125 hydraulic motor, it's always a good idea to consult the manufacturer's documentation or contact their customer support team for assistance. They can provide detailed information on the included accessories and any additional accessories that may be available for your specific model and application.
Is the distribution kit of HMB series five-cylinder hydraulic motor (including HMB045/HMB060/HMB080/HMB100/HMB125/HMB150/HMB200) interchangeable and universal?

Yes. There is the universal for motorcase interface of the HMB series five-cylinder hydraulic motor (including HMB045/HMB060/HMB080/HMB100/HMB125/HMB150/HMB200). And it can also used to be alternatively for distribution kit (including FM3/S03/FM3/SFM3/FM4/S04/SM4/SFM4).
